Stock Code: 000821
Applies reflective film across module gaps and around the perimeter after rear-glass positioning. The application head controls positioning, feeding, heating and pressure; servo positioning and inspection support consistent results.
Specifications
| Compatible module size | L: 1650–2550 mm; W: 990–1450 mm |
| Cycle time | ≤ 13 s |
| Roll material specification | W: 3–12 mm; thickness: ≤ 0.2 mm |
| Power supply | AC 380 V, 3P5W, 50/60 Hz |
| Power | 38 kW |
| Compressed air | 0.6–0.8 MPa; air consumption: 0.8 m³/min |
| Noise level | ≤ 60 dB |
| Weight | 6700 kg |
| Overall dimensions | 6170 × 5040 × 2450 mm |
