Stock Code: 000821
Supports automatic detection, picking, feeding, and sorting of various frame types. Equipped with a vision system for defect identification and intelligent handling, significantly reducing manual intervention. Features frame buffering and non-stop material change, compatible with both manual and AGV loading methods to ensure continuous and efficient production.
Specifications
| Compatible frame size | long side: 1650-2520(mm); short side: 990-1450(mm);
B-side: 30-35(mm) |
| Cycle time | ≤20s |
| Power requirement | AC380V±5%, 3P+1N+1PE, 20A, 50/60Hz |
| Power | 8.5kW |
| Air supply | 0.6-0.8(MPa) |
| Noise | ≤70dB |
| Weight | 2500kg |
| Dimension(L×W×H) | 4900*4700*3000(mm) |
