Stock Code: 000821
Automatically removes sealing tape from G2G modules with precise, clean operation—leaving no residue or scratches. Compatible with various edge sealing types, featuring quick changeover, tidy waste collection, and stable, high-efficiency performance.
Specifications
| Compatible module size | length: 1700-2550(mm); width: 990-1450(mm); thickness: 4-10(mm) |
| Compatible module waveform range | 0-5(mm) |
| Cycle time | ≤18s |
| Feeding method | Long edge feeding (LEL) |
| Tape specifications | width: 30-40(mm); thickness: 0.06-0.10(mm) |
| Power requirement | 380V, 50Hz, AC±5% |
| Power | ≤8kW |
| Air supply | 0.6-0.8(MPa), Consumption: 0.3m³/min |
| Noise | ≤75dB |
| Dimension(L×W×H) | 4200*2500*2100(mm) |
